patchbox.one / 30RU Cat6a Complete Units
Keep your network rack organized in the long term and downtimes at a minimum with the patchbox.one, consisting of 24 retractable cables (available as Cat.6a and Fiber Optic) and the Patchcatch, a 0RU Cable Management.
✓ Twisted Pairs
✓ ISO/IEC 11801 Channel Class Ea
✓ Power your devices with PoE++ (UTP) and PoE (STP)
✓ 23.62″ Installation Depth
✓ For 2-Post Racks and 4-Post Racks
✓ 10-Year Warranty on patchbox.one & its cables
$721.00
Technical Specification
- STP Cable: Flat Cat.6a U/FTP, ISO/IEC 11801 Channel Class Ea, ANSI/EIA/TIA-568 Cat 6A Channel, 500MHz, AWG36, 100% stranded copper, PVC jacket, PoE (802.3af), RoHS compliant
- UTP Cable: Flat Cat.6a U/UTP, ISO/IEC 11801 Channel Class Ea, ANSI/EIA/TIA-568 Cat 6A Channel, 500MHz, AWG30, 100% stranded copper, PVC jacket, PoE++ (802.3bt, Type 3 (60W)), RoHS compliant
- Connector Cat.6a: RJ45 shielded plug, pins gold plated, snagless booted
- Cable length: 6 ft covers 30RU
- Frame: RAL9005 powder-coated steel
- Cassette Profiles: ABS and RAL9001
- Mounting Rails: Steel and RAL9005
- Plastic Parts: Polyoxymethylene POM
- Operating Temperature: 50°F — 140°F
- Ambient Humidity Non-Condensing: 10% – 90%
- Gross Weight: 18.87lbs
- Packaging Dimensions: 31.45″ x 23.11″ x 2.16″ WxDxH
- HS-Code: 8544 4210
Items Included
- 24 x patchbox.one / Cassette / 30RU / Cat.6a
- 1 x patchbox.one / Frame
- 4 x Flanged Hex Nuts
- 4 x Hex Nuts
- 6 x Patchcatch
- 2 x Mounting Rails
Manufacturer Instructions & Manuals
Payment Methods
The new standard in network cabling
The PATCHBOX is a long-term cable management solution that saves companies time and money by significantly improving IT workflow and reducing downtime.
Downtime can be Costly
According to Gartner, one minute of downtime costs $5600. With the PATCHBOX, downtimes are significantly shortened which reduces losses and gets your business back online quickly.
Installation, Maintenance & Troubleshooting
Are up to 8x faster with the PATCHBOX – making work for IT technicians easier and staff & customers happier, while companies benefit financially.
50% More Rack Space
Since each PATCHBOX includes an 0RU Patchcatch cable manager, using other 1RU cable managers is no longer necessary. This means up to 50% more of precious rack space
Manufacture Warranty
We offer a 5-year manufacturer warranty on the PATCHBOX Plus+ and PATCHBOX 365 – including the cables.
There is no space for another Beauty and Beast fairy tale.
Show your network rack some love & affection. With PATCHBOX you have everything you need to transform it from a Beast into a Beauty.
OUR SOLUTIONS
Conventional cabling vs. PATCHBOX
Eight times faster installation: By using PATCHBOX you could patch eight entire network racks in the time of one when using conventional cabling. See the comparison in our video!
